Product Summary

The MAX813LESA+T is an IC MPU supervisory circuit.

Parametrics

MAX813LESA+T absolute maximum ratings: (1)Terminal voltage, VCC: -0.3 to 6V; (2)Input current, VCC: 20mA; (3)Output current: 20mA; (4)Continuous power dissipation: 727mW; (5)Operating temperature range: 0 to 70℃; (6)Lead temperature: 300℃.

Features

MAX813LESA+T characteristics: (1)Output: push-pull, totem pole; (2)Reset: Active high; (3)Reset timeout: 140ms minimum; (4)Voltage-threshold: 4.65V; (5)Operating temperature: -40 to 85℃; (6)Mounting type: surface mount; (7)Supplier device package: 8-SOIC; (8)Packaging: Tape&Reel.

Diagrams

MAX813LESA+T pin connection

Image Part No Mfg Description Data Sheet Download Pricing
(USD)		 Quantity
MAX813LESA+T
MAX813LESA+T
Maxim Integrated Products
Supervisory Circuits uPower Supervisor
Data Sheet
0-2040: $1.33
2040-2500: $1.33
